When the 2022 Ford F-150 Lightning was revealed last month, we received a pretty substantial amount of information on the first-ever all-electric Ford F-150. That includes projected power and range figures, the latter of which may be a tad underrated, as Ford Authority recently reported. Regardless, there is much more data to share in regards to F-150 Lightning specs that’s well worth diving into.
| Measurement | SuperCrew |
|---|---|
| Wheelbase (inches) | 145.5 |
| Overall Length (inches) | 232.7 |
| Cab Height (inches) | 78.9 |
| Width – Excluding Mirrors (inches) | 80 |
| Width – Including Standard Mirrors (inches) | 96 |
| Width – Standard Mirrors Folded (inches) | 83.6 |
| Front Track Width (inches) | 68.1 |
| Rear Track Width (inches) | 68.3 |
| Approach Angle (degrees) | 25.4 |
| Departue Angle (degrees) | 24.2 |
| Breakover Angle (degrees) | 17.8 |
| Ground Clearance (inches) | 8.9 |
| Open Tailgate To Ground (inches) | 37.2 |
| Front Bumper To Back Of Cab (inches) | 155.9 |
| Front Trunk Liftover Height (inches) | 35 |
| Measurement | SuperCrew |
|---|---|
| Seating (occupants) | 5 |
| Front Headroom (inches) | 40.8 |
| Front Legroom SAE Max. (inches) | 43.9 |
| Front Shoulder Room (inches) | 66.7 |
| Front Hip Room (inches) | 62.5 |
| Rear Headroom (inches) | 40.4 |
| Rear Legroom SAE Max (inches) | 43.6 |
| Rear Shoulder Room (inches) | 66 |
| Rear Hip Room (inches) | 62.6 |
| Standard-Range Battery | Extended-Range Battery | ||
|---|---|---|---|
| Drivetrain Layout | Dual eMotor, front and rear transverse mounted, four-wheel drive | ||
| Motors/Configuration | Two inboard three-phase fixed magnet AC motors with internal PMAC controller and transaxles | ||
| Targeted Peak Power (horsepower) | 426 | 563 | |
| Targeted Peak Power (kW) | 318 | 420 | |
| Targeted Peak Torque (pound-feet) | 775 | 775 | |
| Battery Type | Lithium-ion pouch with internal battery management, liquid cooled | ||
| OnBoard Charger Power (input/output kW) | 11.3/10.5 | 19.2/17.6 | |
| Measurement | SuperCrew |
|---|---|
| Inside Length At Floor (inches) | 67.1 |
| Width Between Wheelhouses (inches) | 50.6 |
| Inside Height (inches) | 21.4 |
| Cargo Box Volume (cubic feet) | 52.8 |
| Front Trunk Volume (cubic feet) | 14.1 |
| Standard-Range Battery | Extended-Range Battery | |
|---|---|---|
| Targeted Maximum Payload (pounds) | 2,000 | 1,800 |
| Targeted Maximum Towing With Max Trailer Tow Package (pounds) | 7,700 | 10,000 |
| Front: | Independent double-wishbone with coil-over shocks, stabilizer bar |
| Rear: | Independent semi trailing arms, coil springs, stabilizer bar |
| Standard-Range Battery | Extended-Range Battery | |||
|---|---|---|---|---|
| Level 2 | ||||
| 80A Ford Charge Station Pro 15-100% | 10 Hours | 8 Hours | ||
| 48A Connected Charge Station 15-100% | 10 Hours | 13 Hours | ||
| 32A/240W Mobile Charger 15-100% | 14 Hours | 19 Hours | ||
| Level 3 | ||||
| 150 kW DCFC 15-80% | 44 Minutes | 41 Minutes | ||
| 50 kW DCFC 15-80% | 91 Minutes | 122 Minutes | ||
| Targeted Miles Per Charge/Range* | ||||
| 10 minutes, 150kW DC Fast Charger | 41 Miles | 54 Miles | ||
| 1 hour, 80A Ford Charge Station Pro | 19 Miles | 30 Miles | ||
| 1 hour, 48A Ford Connected Charge Station | 19 Miles | 20 Miles | ||
| 1 hour, 32A/240W Mobile Charger | 14 Miles | 13 Miles | ||
| Targeted EPA-Estimated Range* | 230 Miles | 300 Miles | ||
- * Excludes Platinum models.
| Standard-Range Battery | Extended-Range Battery | |
|---|---|---|
| 32A Ford Mobile Charger | Standard | Standard |
| 48A Ford Connected Charge Station | Optional | Optional |
| 80A Ford Charge Station Pro with Ford Intelligent Backup Power capability | Optional | Standard |
As Ford Authority previously reported, the 2022 Ford F-150 Lightning is available with two different battery packs – a standard range and an extended range unit. The standard range model is expected to produce 426 horsepower and 775 pound-feet of torque, with an estimated 230 miles of range. Meanwhile, the extended range Lightning is expected to produce 563 horsepower and 775 pound-feet of torque, as well as 300 estimated miles of range.
F-150 Lightning specs in terms of payload and towing vary based on the battery pack selected as well. The standard range pickup features a max payload rating of 2,000 pounds versus 1,800 pounds for the extended range battery, while the standard range can tow up to 7,700 pounds, less than the 10,000 pounds the extended range pickup is rated to tow.
The standard range Lightning comes standard with Ford’s 32A mobile charger, while the automaker’s 48A Connected Charge Station and 80A Ford Charge Station Pro are optional. The extended-range version comes standard with both the mobile charger and the Charge Station Pro, while the Connected Charge Station is optional.
In terms of size, the F-150 Lightning measures 232.7 inches long, 78.9 inches high, and 80 inches wide, excluding the side mirrors. Inside, the SuperCrew cab-only EV pickup provides 40.8 inches of front headroom, 40.4 inches of rear headroom, 43.9 inches of front legroom, and 43.6 inches of rear legroom.
One of the most impressive features of the new F-150 Lightning is its massive frunk, or front trunk, which offers 14.1 cubic feet of lockable, covered storage space. Meanwhile, the bed measures 67.1 inches long, 50.6 inches wide, and 21.4 inches tall, providing 52.8 cubic feet of cargo space.
These F-150 Lightning specs are undoubtedly impressive, and yet, some are also preliminary. As we saw with the Ford Mustang Mach-E, range numbers can change, and it’s very possible final figures will be higher. But for now, we’ll just have to wait until those numbers are finalized to find out.
We’ll have much more on the Lightning very soon, so be sure and subscribe to Ford Authority for the latest Ford F-Series news, Ford F-150 news, F-150 Lightning news, and non-stop Ford news coverage.
