Here Are All The 2022 Ford Maverick Specs In One Place

Sponsored

The 2022 Ford Maverick was just revealed this morning, and the preliminary numbers make it quite appealing – a standard hybrid drivetrain offering an estimated 40 miles-per-gallon in the city for less than $20k, though prices can climb quickly when options are tacked on. However, there’s much more to this new compact pickup than those figures, of course. Thus, we’ve assembled a complete list of 2022 Ford Maverick specs here for our readers’ convenience.

2022 Ford Maverick Specs - Exterior
Measurement SuperCrew FWD 2.5L Hybrid SuperCrew FWD 2.0L EcoBoost SuperCrew AWD 2.0L EcoBoost
Wheelbase (inches) 121.1 121.1 121.1
Overall Length (inches) 199.7 199.7 199.7
Height (inches) 68.7 68.7 68.7
Width – Excluding Mirrors (inches) 72.4 72.4 72.4
Width – Including Mirrors (inches) 83.5 83.5 83.5
Width – With Mirrors Folded (inches) 77.9 77.9 77.9
Front Track Width (inches) 63.4 63.4 63.4
Rear Track Width (inches) 62.8 62.8 62.8
Approach Angle (degrees) 20.6 20.6 21.6
Departue Angle (degrees) 21.9 21.9 21.2
Breakover Angle (degrees) 16.6 16.6 18.1
Ground Clearance (inches) 8.3 8.3 8.6
Front Bumper To Back Of Cab (inches) 137.6 137.6 137.6
Front Overhang (inches) 34.1 34.1 34.1
Rear Overhang (inches) 44.5 44.5 44.5
Base Curb Weight (pounds) 3,674 3,563 3,731
Interior
Measurement SuperCrew FWD 2.5L Hybrid SuperCrew FWD 2.0L EcoBoost SuperCrew AWD 2.0L EcoBoost
Front Headroom (inches) 40.3 40.3 40.3
Front Headroom With Moonroof (inches) 38 38 38
Front Legroom (inches) 42.8 42.8 42.8
Front Hip Room (inches) 55.4 55.4 55.4
Front Shoulder Room (inches) 57.3 57.3 57.3
Rear Headroom (inches) 39.6 39.6 39.6
Rear Headroom With Moonroof (inches) 39.5 39.5 39.5
Rear Legroom (inches) 35.9 36.9 36.9
Rear Hip Room (inches) 54.1 54.1 54.1
Rear Shoulder Room (inches) 55.6 55.6 55.6
Passenger Volume (cubic feet) 100.3 100.3 100.3
Storage Capacities
Lift-In Height (inches) 30.1
Pickup Body Height (inches) 20.3
Pickup Body Length At Floor (inches) 54.4
Cargo Width Including Wheel House (inches) 42.6
Exposed Cargo Width (inches) 53.3
Cargo Volume (cubic feet) 33.3
Capability
Rating Type SuperCrew FWD 2.5L Hybrid SuperCrew AWD 2.0L EcoBoost
Maximum Payload (pounds) 1,500 1,500
Maximum Towing 2,000 2,000/4,000*
  • * With 4K Tow Package
Powertrain
2.5L Hybrid (Standard) 2.0L EcoBoost (Optional)
Horsepower 162 250
Torque (pound-feet) 155 277
Total System Output (horsepower) 191 N/A
Hybrid Motor Output (kW) 94 N/A
Peak Hybrid Motor Output (pound-feet) 173 N/A
Transmission PowerSplit electronic continuously variable (eCVT) 8-speed automatic
Body/Drivetrain Layout
Body Type Unibody
Standard Drivetrain Layout Front-Wheel Drive
Optional Drivetrain Layout All-Wheel Drive
Suspension
Suspension 2.5L Hybrid 2.0L EcoBoost
Front Independent MacPherson strut-type suspension with coil springs, twin-tube hydraulic gas-pressurized shocks, stabilizer bars, aluminum lower control arm, steel sub-frame and cast knuckle Independent MacPherson strut-type suspension with coil springs, twin-tube hydraulic gas-pressurized shocks, stabilizer bars, aluminum lower control arm, steel sub-frame and cast knuckle
Rear (FWD) Independent twistbeam rear suspension with integrated, stabilizer bar, Ford patented “force vectoring springs,’ twintube hydraulic gas-pressurized dampers Independent twistbeam rear suspension with integrated stabilizer bar, Ford patented “force vectoring springs,” twintube hydraulic gas-pressurized dampers
Rear (AWD) N/A Independent multi-link trailing arm suspension with twin-tube hydraulic gas-pressurized dampers, coil springs, stabilizer bar, steel sub-frame and cast knuckle
Rear (AWD/FX4) N/A Independent multi-link trailing arm suspension with mono-tube hydraulic gas-pressurized dampers with hydraulic rebound stop, coil springs, stabilizer bar, steel sub-frame and cast knuckle

There are several interesting things to note when looking at these 2022 Ford Maverick specs. For starters, there’s one inch less rear legroom in the hybrid model versus those equipped with Ford’s 2.0L EcoBoost I-4, which is likely due to the location of the battery. On the outside, the Maverick is roughly the same length as the 2021 Ford Explorer, which makes its designation as a compact pickup a bit of a relative term.

It’s also worth noting that the Maverick’s FX4 Off-Road Package features a slightly different rear suspension setup than the regular all-wheel-drive model, as it utilizes mono-tube dampers with hydraulic rebound stops in place of twin-tube dampers.

We’ll have much more on the Maverick very soon, so be sure and subscribe to Ford Authority for more Ford Maverick news and 24/7 Ford news coverage.
